PARAMETER: |
||
15″ Midbass neodymium Speaker |
||
Nominal Diameter |
100/4.0 |
mm/inch |
Nominal Impedance |
8 |
Ohm |
Minimum Impedance |
7 |
Ohm |
Power handling(AES) |
700 |
Watts |
Continuous Program |
1400 |
Watts |
Sensitivity (1W/1m)3 |
98.5 |
dB |
Frequency Range |
48-2500 |
Hz |
Voice Coil Diameter |
100/4.0 |
mm/inch |
Winding Material |
Flat Aluminum |
|
Former Marerial |
GlassFiber |
|
Winding Depth |
21 |
mm |
Magnetic Gap Depth |
12 |
mm |
Flux density |
1.2 |
T |
Thiele-Small parameters |
||
Fs |
48 |
Hz |
Re |
5.3 |
Ohm |
Qes |
0.33 |
|
Qms |
2.803 |
|
Qts |
0.3 |
|
Vas |
101.972 |
mM3 |
No |
4.31 |
% |
X max |
7.5 |
mm |
X mech |
14.5 |
mm |
Mms |
101.496 |
gr |
BI |
23 |
Tm |
Le |
33.321 |
mH |
Cms |
89.196 |
mm/N |
Sd |
89.727 |
M2 |
