PARAMETER: |
||
Nominal Diameter |
545/21 |
mm/inch |
Nominal Impedance |
8 |
Ohm |
Minimum Impedance |
7.9 |
Ohm |
Power handling |
2500 |
Watts |
Continuous Program |
5000 |
Watts |
Sensitivity (1W/1m)3 |
97.5 |
dB |
Frequency Range |
35-1000 |
Hz |
Voice Coil Diameter |
151/6″ |
mm/inch |
Winding Material |
CCAW |
|
Former Marerial |
Glass Fiber |
|
Chassis Material |
Aluminium |
|
Magnet Material |
Neodymium |
|
Flux density |
T |
|
Thiele-Small parameters4 |
||
Fs |
35.3 |
Hz |
Re |
5.7 |
Ohm |
Qes |
0.42 |
|
Qms |
11.6 |
|
Qts |
0.41 |
|
Vas |
170 |
L |
Eta 0 |
3.13 |
% |
X max |
24 |
mm |
X mech |
mm |
|
Mms |
457 |
g |
BL |
38.8 |
N/A |
Le |
2.95 |
mH |
Cms |
0.03 |
mm/N |
Sd |
1847 |
CM2 |
